Messaging Objects Data Model

Data model diagram for Salesforce Scheduler

To view a higher-resolution version of this diagram, right-click (or Control-click on Mac) and select "Open Image in New Tab."

Entities and relationships involved in scheduling, including objects that represent service appointments and resources who can be scheduled to attend appointments

Conversation, Conversation Entry (Off Core), Conversation Participant, Messaging Channel, Messaging End User, Messaging Session, Messaging Session Metrics, Participant, Related Record (Off Core)

See Salesforce Data Model Notation.
